Optical Fiber Support
|
Supports optional optical fiber module
|
|
HDMI Input
|
1x HDMI 2.0 type A
|
|
SDI Video Output
|
1x 12G-SDI on BNC, automatically matches the HDMI video input resolution
|
|
Analog Audio Input
|
2 channels professional balanced analog audio via XLR connectors
Right XLR can be configured for timecode input
|
|
AES/EBU Audio Input
|
4 channels professional 110 ohm balanced digital audio via XLR connectors
Right XLR can be configured for timecode input
|
|
Multi Rate Support
|
Automatic switching between SD, HD, 2K, and 4K
|
|
Updates and Configuration
|
USB or Ethernet
|
|
Re-Clocking
|
Yes
|
|
SD Format Support
|
525/29.97 NTSC, 625/25 PAL
|
|
HD Format Support
|
1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60
|
|
2K Format Support
|
2048 x 1080PsF23.98, 2048 x 1080PsF24, 2048 x 1080PsF25, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25
|
|
4K Format Support
|
3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60
|
|
SDI Compliance
|
SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M, SMPTE 297M for Optical Fiber SDI
|
|
SDI Video Rates
|
SDI video connections are auto switching between SD-SDI, HD-SDI, high definition level B 3G-SDI, 6G-SDI, and 12G-SDI
|
|
SDI Video Sampling
|
4:2:2 and 4:4:4
|
|
SDI Audio Sampling
|
Television standard sample rate of 48 kHz and 24-bit
|
|
SDI Color Precision
|
YUV 4:2:2 and RGB 4:4:4 in HD, 2K, and 4K
|
|
SDI Color Space
|
REC 601, REC 709
|
|
HDMI Format Support
|
525/29.97 NTSC, 625/25 PAL, 1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25, 3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60
|
|
HDMI Color Space
|
REC 601, REC 709
|
|
HDMI Color Precision
|
YUV 4:2:2 and RGB 4:4:4 in HD, 2K, and 4K
|
|
Software Control
|
Mac OS X and Windows software upgrade via USB and Ethernet
|
|
Internal Software Upgrade
|
Via included updater application
|
|
Basic Settings Control
|
Mini Switches, USB, and Ethernet via free software utility
|
|
Power Supply
|
1x built-in international AC power supply with IEC C14 inlet
IEC power cable required (not included)
90 - 240 VAC input
|
|
Power Over Ethernet
|
Can be powered via 48 VDC using PoE (Power-over-Ethernet)
|
|
Power Consumption
|
15 W
|
|
Operational Voltage Range
|
90 - 240 VAC
|
|
Operating Temperature
|
32 to 104°F (0 to 40°C)
|
|
Storage Temperature
|
-4 to 140°F (-20 to 60°C)
|
|
Relative Humidity
|
0 to 90% non-condensing
|
|
Dimensions
|
W x H x D: 5.5 x 1.8 x 6.7 (14 x 4.6 x 17 cm) (with SDI port included)
|
|
Weight
|
1.3 lb (0.6 kg)
|
